GridForge Documentation

GridForge is a power-system configuration and formulation toolkit for research workflows. It is designed for machine learning and optimization co-design tasks in power systems.

Motivation

When co-designing machine learning and optimization tasks, we often need spatiotemporal data for all buses in the grid. But 1. Open-source load, solar, and wind data do not match the scale of the test grid (e.g., the nominal powers do not match). 2. Power system analysis tools such as PYPOWER/MATPOWER support basic OPF or dispatch tasks; however, when considering more complex tasks, such as unit commitment, extra operational configurations are needed.

No matter how complex your target grid is (IEEE 14-bus, RTE 2868, etc.), GridForge can help you efficiently construct the grid operational model and assign the time-series data for all buses.

GridForge helps you start from a standard power-system case (e.g., PYPOWER/MATPOWER), add or modify grid assets with YAML files, attach user-defined bus-level time-series data, and load everything into Python for optimization modeling.

GridForge is developed by Wangkun Xu (GitHub).

Installation

Install the latest commit:

pip install "git+https://github.com/xuwkk/gridforge.git"

For local development:

git clone https://github.com/xuwkk/gridforge.git
cd gridforge
python -m venv .venv
source .venv/bin/activate
pip install -e ".[full]"

Workflow At A Glance

GridForge separates the workflow into explicit artifacts:

1. Write a grid YAML file, either by hand or through the visual app, that says how to modify a base PYPOWER/MATPOWER case and which custom assets, such as load, solar, wind, or storage, should be added.
2. Build an Excel workbook from that YAML file. The workbook is the static grid case: buses, generators, branches, and custom asset sheets.
3. Assign source CSV profiles to generated buses. This creates one case-specific bus_<BUS_IDX>.csv file for each bus that needs time-series data.
4. Load the workbook with Grid(...) and the time-series files with Data(...).
5. Use those objects to build your own optimization model, for example in CVXPY.

Documentation Map

• Workflow: the end-to-end GridForge pipeline.
• Visual Config App: the Streamlit app for building and previewing grid YAML files.
• Configuration: the YAML schema and construction logic for Step 1.
• Bus Data Assignment: how source data files are mapped to generated buses in Step 3.
• Grid And Data Access: what Grid(...) and Data(...) expose for optimization code in Step 5.
• TX-123BT Workflow: optional public source-data preparation.
• Examples: runnable examples included in the repository.
• Copyright And License: project license and third-party data notes.

For a short install-and-run example, start from the repository README. For the full construction path, continue with the workflow guide.
